ASM/Siemens placement machine DP motor failure

The DP motor is one of the key components in the placement machine. It drives the movement of the suction nozzle by controlling the rotation of the motor. When the DP motor is working properly, the nozzle can accurately pick up and place components. If the DP motor fails, the suction nozzle will not be accessible normally, which will affect the normal operation of the placement machine. This article will introduce some solutions to the problem that the DP motor cannot access the nozzle to help you solve the problem quickly.

03113016-2

When the DP motor fails, it may cause the following problems:

1. Incoherent movement of the suction nozzle: DP motor failure may cause the movement of the suction nozzle to become incoherent, thus affecting the

operational stability of the placement machine.

2. Unstable nozzle speed: DP motor failure may cause the speed of the nozzle to be unstable, and fast or slow nozzle movement may occur, thus affecting

the accuracy of component pasting.

3. The suction nozzle stops moving: A failure of the DP motor may cause the suction nozzle to stop moving, causing the placement machine to not work properly.

4. Increased suction nozzle noise: DP motor failure may cause abnormal noise when the suction nozzle moves, which may be due to damage or wear of internal parts of the motor.

5. Inaccurate patch position: DP motor failure may cause the movement of the suction nozzle to be inaccurate, resulting in inaccurate patch position and possible offset or misalignment.

For DP motor nozzle failure, the following solutions can be taken

1. Check the connection

First, we need to check the connection between the DP motor and the nozzle. Make sure the cables are not loose or damaged. If there is any problem with the connection line,

it should be replaced or repaired in time. At the same time, also check whether the connector is inserted correctly to ensure a stable connection.

2. Check the status of the nozzle

Secondly, we need to check the status of the nozzle. Sometimes, the suction nozzle may be clogged with foreign matter, making it impossible to access the component properly.

Use a nozzle cleaner or cotton swab to clean the nozzle and make sure it is clear. In addition, check whether the suction nozzle is worn or deformed. If so, replace the suction nozzle in time.

3. Check the nozzle vacuum source

If there is no problem with the connection and the nozzle, then we need to check the vacuum source of the nozzle. Make sure the vacuum source is working properly and providing

adequate suction. This can be confirmed by checking components such as vacuum pumps, vacuum lines, and filters. If problems are found, the faulty parts should be repaired or replaced in time.

4. Check the DP motor

If none of the above methods solve the problem, the fault may lie in the DP motor itself. In this case, it is recommended to contact a professional repair service provider such as Geekvalue

Industrial. They have experienced technicians who can perform comprehensive inspections and repairs on DP motors. They may need to disassemble the DP motor and examine the condition

 of its internal parts to determine the source of the problem. Based on the results of the inspection, they can provide appropriate solutions and repair or replace faulty parts.

During the maintenance process, Geekvalue Industrial will also ensure that all operations comply with safety regulations and provide post-maintenance testing and debugging. Their goal is to

ensure equipment is back up and running and downtime is minimized.
