Working Principle
The working principle of the TH placement head includes the following steps:
Pick up components: The TH placement head uses a vacuum nozzle to pick up two components.
Optical centering: The components are centered by the optical system during delivery to the placement position.
Rotate components: Rotate the components to the required placement angle.
Place components: Place the components accurately on the specified position of the circuit board.
Applicable scenarios
TH placement heads are particularly suitable for special components that require high-precision placement, such as those that require a gripper. This design enables the TH placement head to complete the placement task of special components at high speed and efficiency.
We also supply following Siemens Spare parts :
| 00341780-02 | DP Motor | 03058627-02 | CP20A DP Motor |
| 03102532-01 | CP20P DP Motor | 03050314S03 | CPP DP Motro |
| 03072785S01 | CP20A Generator | 03106620S01 | CP20P Generator |
| 03152828S01 | CPP Generator | 03055438-01 | CPP Generator |
| 03058802-02 | TH Generator | 03038908S01 | Z-axis Motor |
| 03058631-02 | CP20A Z-axis Motor | 03061102S01 | CP Z-axis Motor |
| 03005123S01 | CP20A Distributor | 03081381-01 | CPP Distributor |
| 03058629-01 | CP20A Round Plate control unit | 03115167-01 | CPP Disc control unit |
| 03003426S02 | Camera 23 Component | 03054153-04 | 2003 Nozzle |
| 03013307-01 | 1001Nozzle | 03057850S03 | 2007 Nozzle |
| 03054923-03 | 2033 Nozzle | 03059921S03 | 2038 Nozzle |
| 03083001S03 | CP20A Component Sensor | 03037106-01 | CPP Component Sensor |
| 03092400-02 | CP20P Sensor | 03133310-01 | P2 Sensor |
| 03039099-01 | CPP Sliding block | 03060811-01 | TSP 400 track board |
| 03087642-01 | TSP 420 Track board | 03055072-01 | Head Board |
| 03054790S01 | CPP SCS Control Card | 03115454-01 | Image Card |
| 03057377S02 | WPC Control Card | 03037845-01 | CP20A Round Holder |
| 03091256-01 | X-axis grading scale | 03091255-02 | Y-axis grading scale |
| 03092666-02 | Track Solenoid valve | 03092667S03 | Track Solenoid valve |
| 03059084-01 | Y-axis Sliding block | 03109668-01 | HCU |
| 03052200-01 | GCU Computer | 03059666-01 | FCU |
| 03059623-01 | FCU | 03079685-02 | Ring RACE |
| 03002942-01 | Shield Card | 03083835-01 | New mode DP Motor |
