ASM CPP Placement head PN:03053528

CPP patch head follows the working principle of "pick-and-place". It picks up two components, performs optical alignment and rotates to the required placement angle during the process of sending them to the placement position. This working principle is particularly suitable for the fast and accurate placement of large components.

Performance characteristics

‌High precision‌: The CPP patch head has the characteristics of high precision and is suitable for electronic components that require high-precision placement.

‌High speed‌: The CPP patch head can be placed at a higher speed and is suitable for the needs of large-scale production.

‌Flexibility‌: The design of the CPP patch head enables it to adapt to different placement needs and is suitable for various types of components.

Common faults and maintenance methods

Common faults of the CPP patch head include zero point loss, Z-axis motor servo current overlimit, grating ruler damage, etc. These faults will cause the patch head to fail to work properly. Maintaining and repairing these faults usually requires professional technical teams and equipment. For example, a Z-axis motor failure can be repaired by a professional technical team instead of directly replacing the motor. ‌

In summary, ASM CPP placement head plays an important role in the electronics manufacturing industry with its high precision, high speed and flexibility, but its maintenance and troubleshooting require professional technical support.

We also supply following Siemens Spare parts :

00341780-02       DP Motor
03058627-02       CP20A DP Motor
03102532-01       CP20P DP Motor
03050314S03      CPP DP Motro
03072785S01      CP20A Generator
03106620S01      CP20P Generator
03152828S01      CPP Generator
03055438-01        CPP Generator
03058802-02        TH Generator
03038908S01       Z-axis Motor
03058631-02        CP20A Z-axis Motor
03061102S01       CP Z-axis Motor
03005123S01       CP20A Distributor
03081381-01        CPP Distributor
03058629-01        CP20A Round Plate control unit
03115167-01         CPP Disc control unit
03003426S02       Camera 23 Component
03054153-04         2003 Nozzle
03013307-01        1001Nozzle
03057850S03        2007 Nozzle
03054923-03         2033 Nozzle
03059921S03       2038 Nozzle

03083001S03      CP20A Component Sensor
03037106-01       CPP Component Sensor
03092400-02       CP20P Sensor
03133310-01       P2 Sensor
03039099-01       CPP Sliding block
03060811-01       TSP 400 track board
03087642-01       TSP 420 Track board
03055072-01       Head Board
03054790S01      CPP SCS Control Card
03115454-01       Image Card
03057377S02      WPC Control Card
03037845-01       CP20A Round Holder
03091256-01       X-axis grading scale
03091255-02       Y-axis grading scale
03092666-02        Track Solenoid valve
03092667S03       Track Solenoid valve
03059084-01        Y-axis Sliding block
03109668-01        HCU
03052200-01       GCU Computer
03059666-01       FCU
03059623-01       FCU
03079685-02       Ring RACE
03002942-01       Shield Card
03083835-01       New mode DP Motor
03093314-01       Track Belt
