Ekyuma ekisala PCB kye ki

SMT splitter kye kyuma ekikozesebwa ennyo okusala circuit boards. Ekoleddwa okugabanyaamu obubaawo bwa SMT PCB okusobola okutuuka ku kusala okutuufu okwa bipande bya circuit. Eriko emirimu mingi egyategekebwa okutumbula obutuufu n’obulungi bw’okugabanyaamu circuit board.

Ebika bya SMT PCB Cutting Machines bimeka?

Okusinga waliwo ebika bya SMT PCB Cutting Machines bino wammanga:

1. Simple desktop milling cutter splitter: Splitter eno esaanira okufulumya batch entono, nga erina sayizi y’okusala entono, esaanira okuteekebwa ku desktop, okukola ennyangu, era esaanira abakozesa abalina embalirira entono.

2. Single-table milling cutter splitter: Splitter eno erina sayizi y’okusala ennene era esaanira okufulumya mu bitundu ebya wakati. Ebyuma bino bikwata ekitundu kitono era ensengeka yaabyo eyawukana okusinziira ku babikola.

3. Online milling cutter splitter: Esaanira okufulumya ebyuma bya layini yonna ebya SMT, esobola okutegeera okufulumya okw’otoma awatali kuyingirira mu ngalo n’okulongoosa obulungi bw’okufulumya.

4. Jigless milling cutter splitter: Splitter eno tekyetaagisa jigs ezikoleddwa ku mutindo, era ekozesa fixture okutereeza PCB board okusala, nga kino kyangu okukola1.

5. Milling cutter + knife board splitter: esaanira circuit boards ezeetaaga okukola V-cutting ne stamp hole processes mu kiseera kye kimu, nga zirina emirimu ebiri mu gumu okutumbula efficiency okufulumya.

Okugatta ku ekyo, okusinziira ku nkola ez’enjawulo ez’okusala n’enzimba, SMT PCB Cutting Machine nayo esobola okwawulwamu ebika bino wammanga:

1. Ekyuma ekigabanya bboodi ya layisi:nga ekozesa okusala kwa layisi, erina ebirungi eby’obutuufu obw’amaanyi, okukola obulungi ennyo, n’obutaba na bucaafu, era esaanira okukolebwa n’obwetaavu obw’obutuufu obw’amaanyi2.

2. Ekyuma ekigabanya olubaawo mu makanika:Sipiidi y’okusala ya mangu era esaanira okukola mu bungi, naye obutuufu buba wansi2.

3. Ekyuma ekigabanya ebipande bya plasma:nga okozesa okusala kwa pulasima, ekifo ekisala kiba kipapajjo, era kituukira ddala mu mbeera z’okufulumya ezeetaaga ebbugumu ettono2.

4. Ekyuma ekigabanya bboodi ya CNC:entambula y’ekintu ekisala efugibwa enkola ya CNC, esaanira okusala okuzibu okukoona, n’obutuufu obw’amaanyi n’obulungi2.

Ebika bino eby’enjawulo ebya SMT PCB Cutting Machine birina engeri zaabyo era bituukira ddala ku byetaago by’okufulumya n’embeera ez’enjawulo. Abakozesa basobola okulonda ekyuma ekigabanya bboodi ekituufu okusinziira ku byetaago byabwe ebitongole.

Omulimu omukulu ogw’ekyuma ekisala PCB

Omulimu omukulu ogwa board splitter kwe kusala obulungi era mu ngeri ennungi circuit boards ez’ekitundu ekinene mu bitundutundu ebitonotono okutuuka ku kugabanya circuit boards. 1. 1.

Ekyuma ekiggyamu ebipande kituukiriza omulimu guno nga kiyita mu nkola ez’enjawulo ez’okusala, omuli okusala ekyuma, okusala ekyuma ekisala, okusala layisi, n’ebirala Enkola zino ez’okusala zituukira ddala ku bika bya circuit boards eby’enjawulo n’ebyetaago okukakasa obutuufu n’obutakyukakyuka bw’okugabanya.

Ebika by’ebyuma ebiggyamu ebipande mulimu ebyuma ebiggyamu ebipande eby’ekika kya knife, ebyuma ebiggyamu ebipande eby’ekika kya punch, ebyuma ebiggyamu ebipande eby’ekika kya milling cutter n’ebyuma ebiggyamu ebipande mu ngeri ya laser. Buli kyuma ekiggyamu ebipande kirina ebirungi n’ebibi byakyo. Okugeza, ekyuma ekiggyamu ebipande eky’ekika ky’ekiso kirina ssente ntono naye kisobola okukola straight-line depaneling yokka, ekyuma ekiggyamu ebipande eky’ekika kya punch kya mangu naye nga kirina situleesi, ekyuma ekiggyamu ebipande eky’ekika kya milling cutter kisobola okuggyamu ebipande mu ngeri yonna naye nga kirina waggulu omuwendo, era ekyuma ekiggyamu ebipande (laser depaneling machine) tekirina situleesi naye nga kya bbeeyi.

Engeri y'okulabirira Ekyuma ekisala ekya SMT PCB

Ensonga enkulu zino wammanga zeetaaga okufaayo ng’okozesa ekyuma ekisala ekya SMT PCB:

1. Okukola obulungi: Bw’oba ​​okozesa ekyuma ekiggyamu ebipande ekya SMT, obukuumi bw’omukozi bulina okukakasibwa. Ebanga wakati w’ebisala ebya waggulu n’ebya wansi lirina okukeberebwa nga tonnaba kukola. Kikugirwa nnyo okuteeka omukono gwo mu kyuma okwewala obubenje. Ekyuma bwe kiba nga kikola, toggyawo pulati ekuuma okwetooloola ekyuma 12.

2. Teeka bulungi bboodi ya PCB: Teeka ekifo eky’okwawula olubaawo lwa PCB ku kifo ekinywevu eky’ebikozesebwa era otambuze eky’okwawula bboodi ya PCB mu bbanga. Kakasa nti bboodi ya PCB eteekeddwa mu ngeri enywevu okwewala okukyukakyuka kw’okubeebalama oba okwonooneka kw’ekisenge ky’amasannyalaze mu nkola y’okwawula bboodi12.

3. Okuddaabiriza buli lunaku: Okwoza n’okulabirira ebyuma buli kiseera okukuuma obutuufu n’obulamu bw’ebyuma nga bikola. Kozesa omwenge okusiimuula ekiwujjo ky’ekyuma n’ekintu ekikozesebwa, kebera oba sikulaapu zisumuluddwa, era osiige amafuta ku muggo gwa slide ne bbeeri23.

4. Obukuumi bw’amasannyalaze: Obukuumi bw’amasannyalaze bulina okukolebwa nga bukola, era omukozi alina okwambala empeta y’amasannyalaze okuziyiza amasannyalaze agatali gakyukakyuka okwonoona olubaawo lwa PCB23.

5. Okuddaabiriza ebyuma: Singa ekyuma ekikutula bboodi tekiba kya bulijjo era nga kyetaaga okuddaabirizibwa, sooka okakasa nti omuguwa gw’amasannyalaze guggyiddwa ku socket okwewala obulabe bw’okukubwa amasannyalaze

Lwaki otulonda okugula PCB Cutting Machines?

1. Kkampuni erina amakumi g’ekyuma ekisala SMT PCB mu sitoowa omwaka gwonna, era byombi omutindo gw’ebyuma n’obudde bw’okubituusa bikakasiddwa

2. Tulina ttiimu y’ekikugu ey’ekikugu esobola okuwa obuweereza obw’ekikugu obw’ekifo kimu ng’okusengula, okuddaabiriza, okuddaabiriza, okuddaabiriza bboodi, okuddaabiriza mmotoka, okulongoosa pulogulaamu, okutendekebwa mu by’ekikugu, n’ebirala ku SMT PCB Cutting Machine

3. Tetukoma ku kuba na bitundu bipya n’eby’omulembe mu sitoowa, tulina n’ebitundu by’awaka, gamba ng’ebyuma ebisala ebyuma, bye tulina ekkolero lyaffe lye tulina okufulumya, nga kino okutuuka ku kigero ekinene kiyamba bakasitoma okukendeeza ku nsaasaanya y’emirimu n’okwongera ku magoba.

4. Ttiimu yaffe ey’ekikugu ekola essaawa 24 emisana n’ekiro mu ssifiiti. Ku bizibu byonna eby’ekikugu ebisanga amakolero ga SMT, bayinginiya basobola okutegekebwa okuddamu okuva ewala essaawa yonna. Ku bizibu eby’ekikugu ebizibu, bayinginiya abakulu nabo basobola okusindikibwa okukola emirimu egy’ekikugu mu kifo.

Mu bufunze, PCB splitter awatali kubuusabuusa kyuma kikulu nnyo eri SMT. Nga olondawo abagaba ebintu abafaanagana, ng’oggyeeko ebirungi ebiri mu yinvensulo n’emiwendo, okufaayo okw’enjawulo kulina okussibwa ku oba omugabi alina ttiimu ey’ekikugu ey’ekikugu, ekola kinene nnyo mu kukola ebyuma mu ngeri eya bulijjo mu biseera eby’omu maaso.
